KeyInCode 5560 KWB Smart Wi-Fi Trim Lock for Exit Bars

$785.00
$785.00

SHIPPING DELAY: All orders will ship after April 22, 2026.

ANSI Grade 1, BLE & Wi-Fi Enabled Lockset

The KIC-5560 KWB Wi-Fi-enabled smart lock is a heavy-duty, commercial-grade smart lock designed for large enterprises, offices, and commercial properties.

This lock utilizes built-in Wi-Fi to connect directly to the internet via existing Wi-Fi networks, allowing property owners to manage access remotely and affordably extend access control deeper into buildings beyond traditional wired exterior doors.

The KIC-5560 Lever Lock with cylindrical latch is managed through RemoteLock’s intuitive cloud-based software and mobile app, offering seamless wireless configuration. Users can adjust settings, manage access credentials, view activity history, receive alerts, and more.

Designed for maximum flexibility, KeyInCode locks support a variety of credential types, including PIN codes, temporary guest PINs, ReadyPINs (algorithm-generated), and MIFARE smart cards. BLE is only used for commissioning the lock.

Setup & Commissioning

Commissioning is completed through the KIC Mobile App (iOS & Android)

  • Install and power on the lock.

  • Pair and commission in the KIC app

  • Connect KIC account to RemoteLock through the KIC KoreLine integration tile

  • Manage all access, permissions & logs in RemoteLock

  • The workflow mirrors other smart lock platforms:

  • OEM app first → then connect to RemoteLock cloud.

*Exit Trim only (Exit Bar not included)*

Designed for maximum flexibility, KeyInCode locks support a variety of credential types, including PIN codes, temporary guest PINs, ReadyPINs (algorithm-generated), and MIFARE smart cards.


Compatible with the following exit devices/exit bars:

  • KeyinCode KIC-5000-EB Rim Exit Bar

  • KeyinCode KIC1000 Rim Exit Bar

  • Von Duprin 99 RIM Exit Device

  • Marks M9900 Rim Exit Device

  • Detex Advantex 10 Rim Exit Device

  • Dorma 9300 Rim Exit Device


Not Compatible:

  • Sargent 8800 Rim Exit Device

  • Precision 2100 Rim Exit Device

  • Hager 4500 Rim Exit Device

  • Corbin Russwin 5200 Rim Exit Device

  • Yale 7100 Rim Exit Device

Features:

  • Brand: KeyInCode

  • Device Type: Exit Trim (Exit Bar not included)

  • Dimensions:

    • Exterior 7 5/8(H) x 2 3/4(W) x 2 3/4(D) in.

    • Interior 7 5/8(H) x 2 3/4(W) x 2 3/4(D) in.

  • Batteries: 4 AA

  • Code Capacity: 3500

  • Code Length: 4-10 digits

  • Connectivity: 2.4GHz Wi-Fi (IEEE 802.11 b/g/n)

  • Event Audit Trail: 1000 stored offline

  • Handing: Field Reversible

  • Access Types: PIN, ReadyPIN, MiFare Classic Credentials, Mobile

  • Backset: 2 3/8" (60mm) & 2 3/4" (70mm)

  • Door Thickness: 1 3/8" -2 3/8" (35mm-60mm)

  • Rating: AN:SI/BHMA A156.25-2018, Grade 2, ANSI/BHMA A156.2-2017

  • Finish: 626 (Stainless Steel) and 676 (Matt Black)

  • Warranty: 1 Year Warranty by Manufacture

Included:

  • Outside Trim Lock only (Exit Bar purchased separately)

  • Mounting Hardware

  • Templates

  • 2 Keys

  • Installation Guide

  • Batteries not included



  • all locks
  • KeyInCode
Finish:
