Yale Pro 2 Commercial Interconnected Deadbolt - Touchscreen - with Augusta Lever - Keyed. YMC624

$449.99
$449.99

SKU: YMC624

Yale products do not ship outside the U.S. - Ships in 3-4 weeks

The Yale Pro 2 Interconnected Lock gives property owners smart and secure keyed access for apartments and multi-family entry doors. Designed for regions requiring single action egress, this lock combines the simplicity of a deadbolt with keyed convenience, allowing residents to quickly enter and exit their units. For property managers, the Pro 2 integrates effortlessly with smart property systems like Wi-Fi, Z-Wave Plus, and Zigbee, creating a streamlined, connected access solution across the property

Features:

  • Single Action Egress

  • Meeting all code requirements, multi-family apartment doors can be unlocked in one motion.

  • Built-in Security

  • Depend on a tamper-proof, pick-resistant lock with an alarm if forcibly removed.

  • Ultimate Control

  • Create and manage up to 500 unique codes scheduled for residents, staff, and maintenance - temporary or permanent.

  • Design Variety

  • Choose from a push button or touchscreen design in a variety of finish options. Expect wear-resistant and long-term durability.

  • Flexible Connectivity

  • Connect through Bluetooth, Wi-Fi, Z-Wave Plus, Zigbee, and manage with partner apps to expand your smart building solutions.



 Product Order String:

 Lever Style: AU- Augusta Lever

Rose: R – Round

Bore Hole Configuration: 4 – 4” Center to Center Borehole or 5 – 5.5.” Center to Center Borehole

Handing: (lock is field reversible) RH – Right Handing

 Latch/Deadbolt Face Plate: RC – Round Corner Latch

Strike Plate Style: R – Round Corner

Pins: 6PN – 6 pin

Keyway:  KWKD – Kwikset Keyed Different

Door Thickness: 1-3/4", 2", 2-1/4"

Edge Bore: 1" diameter

Backset: 2-3/8" or 2-3/4"

Face Bore: 2-1/8"

Latch: 1/2" throw latch, 1" deadbolt

Lever: AU- Augusta Lever

Strike: 2-1/4”" full lip strike, 2-3/4" x 1/8"

Handing: Field Reversible

Operating Temperature: -13F (-25C) to 151F (66C)

ANSI/BHMA: ANSI/BHMA A156.12 Grade 1

UL/cUL: UL Listed for use on fire doors up to 90 minutes

 Warranty: 2-year electrical warranty;  3-year mechanical and finish warranty from Yale

 Windstorm Certification: A250.13 Windstorm



Included:

  • Yale Pro 2 Interconnected Lock

  • Smart Module (WF1, CB1or ZW4)

  • *BLE models do not come with a module*

  • AU- Augusta Lever

  • DoorSense

  • Installation Guide

  • Screws

  • Door Template

  • 6 AA Batteries

  • 2 Keys
