Yale

Yale Pro 2 Commercial Mortise Touch Screen Lock with Augusta Lever & Deadbolt Key-free YMM644-DB

$684.99
$684.99

SKU: YMM644-DB

Yale products do not ship outside the U.S. - Ships in 3-4 weeks

The Yale Pro® 2 Mortise Lock is the smart keypad upgrade for traditional mortise locks, delivering key-free access for high-traffic entryways in apartments and multi-family buildings, like common shared spaces. While residents and guests enjoy seamless keyed-free entry, property owners gain peace of mind with a lock built for durability and enhanced high security. For property managers, the Pro 2 integrates effortlessly with smart property systems like Wi-Fi, Z-Wave Plus, and Zigbee, creating a streamlined, connected access solution across the property



Features:

 Single Action Egress

  • Meeting all code requirements, multi-family apartment doors can be unlocked in one motion.

  • Built-in Security

  • Depend on a tamper-proof, pick-resistant lock with an alarm if forcibly removed.

  • Ultimate Control

  • Create and manage up to 500 unique codes scheduled for residents, staff, and maintenance - temporary or permanent.

  • Design Variety

  • Choose from a push button or touchscreen design in a variety of finish options. Expect wear-resistant and long-term durability.

  • Flexible Connectivity

  • 6Connect through Bluetooth, Wi-Fi, Z-Wave Plus, Zigbee, and manage with partner apps to expand your smart building solutions.



Product Order String:

Lever: AU – Augusta

 Rose: R – Round

Optional Deadbolt: (If no option selected, deadbolt will not be included) DB – With Deadbolt

 Handing: (Lock is field reversible) RH – Right Hand

Pins:  6PN – 6 Pin

Keying Optional: KWKD – Kwikset Keyed Different


Product Specifications:

Door Thickness: 1-3/4", 2", 2-1/4"

Edge Bore: 1"

Backset: 2-3/4"

 Latch: 3/4" Throw Latch, 1" Deadbolt (optional)

 Lever: AU- Augusta Lever

 Strike: 124mm x32mm x2.5mm with Lip Standard

Handing: Reversible

Operating Temperature: -13F (-25C) to 151F (66C)

ANSI/BHMA: ANSI/BHMA A156.13 Grade 1

UL/cUL: Functions are UL - cUL Fire Listed for use on fire doors having a rating up to and including 3-hours

Warranty: 2-year electrical warranty; 3-year mechanical and finish warranty

Windstorm Certification: A250.13 Windstorm



Included:

  • Yale Pro® 2 Mortise Lock

  • Smart Module included for CB1 or ZW4

    • *BLE and WF1 models do not come with a module*

  • AU- Augusta Lever

  • Installation Guide

  • Screws

  • Door Template

  • 6 AA Batteries
